T1500G-10PS
6935364080259
TP-LINK
namizni
Smart
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p
8x 10/100/1000Mbps RJ45, 2x SFP
8
10/100/1000Mbps
prepustnost: 20 Gbps
število paketov na sekundo: 14,9 Mbps
8x PoE 802.3af, skupno do 53W
Quality of Service
802.1p CoS/DSCP priority
4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
Voice VLAN
L2 Features
IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 6 aggregation groups, containing 4 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loop back detection
802.3x Flow Control
LLDP, LLDP-MED
VLAN
Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
Access Control List
L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports
Security
Port Security
DHCP Snooping
IP-MAC-Port Binding
ARP Inspection
802.1x and Radius Authentication
SSH v1/v2
SSL v3/TLSv1
Broadcast/Multicast/Unknown-unicast Storm Control
Dos Defend
Management
Web-based GUI
Command Line Interface(CLI) through telnet
SNMP v1/v2c/v3,compatible with public MIBs and
TP-Link private MIBs
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Time Setting: SNTP
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
Dual Image
64,9W (največ s PoE). 9,9W (brez PoE)
209 mm (D) x 126 mm (G) x 26 mm (V)
24 mesecev
- 1500G-10PS Switch
- napajalni kabel
- gumijaste noge
- CD
