ASUS PRIME B650M-A AM5 II-CSM mATX DDR5 VGA DP HDMI USB3.2 ARGB osnovna plošča
Program ASUS Corporate Stable Model (CSM) je zasnovan tako, da zagotavlja stabilne matične plošče za vsa podjetja z do 36-mesečno dobavo, obvestilom o iztrošenosti in nadzorom ECN ter programsko opremo za upravljanje IT - ASUS Control Center Express.
90MB1EH0-M0EAYC
4711387025543
ASUS
AM5
AMD B650
Micro ATX
4x DDR5 DIMM, max do 6400 (OC), maks. 128 GB (UDIMM)
1x PCIe 4.0 x16
2x PCIe 4.0 x1
1x M.2/?M-Key (PCIe 5.0 x4, 2280/?2260/?2242)
1x M.2/?M-Key (PCIe 4.0 x4, 2280)
1x M.2/?E-Key (PCIe, 2230)
SATA 6 Gb/s
2 x reži M.2 in 4 x vrata SATA 6 Gb/s
7.1 (Realtek ALC897)
Zadaj USB: Skupno 4x port
2x USB 3.2 Gen 1 ports (2 x Type-A)
2x USB 2.0 ports (2 x Type-A)
Spredaj USB: Skupno 6x port
1x USB 3.2 Gen 1 header podpira dodatna 2 USB 3.2 Gen 1 ports
2x USB 2.0 headers podpira dodatne 4 USB 2.0 ports
2x USB 3.2 Gen 2 ports (2x Type-A)
2x USB 3.2 Gen 1 ports (2x Type-A)
4x USB 2.0 ports (4x Type-A)
1x DisplayPort
1x VGA port
1x HDMI® port
1x Realtek 2.5Gb Ethernet port
3x Audio jacks
1x BIOS FlashBack™ button
1x PS/2 tipkovnica/miška combo port
Ventilator in hlajenje
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
3x 4-pin Chassis Fan headers
Napajanje
1x 24-pin Main Power connector
1x 8-pin +12V Power connector
Storage related
2x M.2 slots (Key M)
4x SATA 6Gb/s ports
USB
1x USB 3.2 Gen 1 connector (supports USB Type-C )
1x USB 3.2 Gen 1 header podpira 2 dodatna USB 3.2 Gen 1
2x USB 2.0 headers podpira 4 dodatne USB 2.0
Drugo
3x Addressable Gen 2 headers
1x Aura RGB header
1x Clear CMOS header
1x COM Port header
1x Front Panel Audio header (AAFP)
1x S/PDIF Out header
1x Speaker header
1x SPI TPM header (14-1pin)
1x 10-1 pin System Panel header
36 mesecev
